Cadence SPB OrCAD X/Allegro X 2023 v23.10.000 for PC Windows

Description

Overview of Cadence SPB Allegro and OrCAD Benefits

Cadence Allegro and OrCAD products are integrated directly with Windows; the products support hardware and peripherals supported by Windows. Can obtain a list of hardware and peripherals officially supported by Windows from the Microsoft web page.

The products require updating specific Microsoft libraries in the Windows directory. You must install the Cadence software using either a standalone or client install. You may not be able to point to the software without installing it.

Overview of Cadence SPB Allegro and OrCAD Features

• Suitable graphical user environments and display circuits using icons
• OrCAD Capture and Capture CIS schematic design circuits in a robust environment
• Ability to design PCB (Printed Circuit Board stands and means the board or PCB)
• Has an extensive library full of components and electronic devices
• Advanced simulation and analysis of electronic circuits in a graphical environment PSpice
• Environment Orcad PCB Designer / Editor to design and edit PCB
• Ability to interact with MATLAB and Simulink software

System Requirements and Technical Details

Operating System

Microsoft Windows 7 Professional, Enterprise, Ultimate or Home Premium (64-bit); Windows 8 (64-bit) (All Service Packs); Windows 10 (64-bit); Windows 2008 R2 Server; Windows 2012 Server (All Service Packs).
Cadence Allegro and OrCAD (Including EDM) products do not support Windows 7 Starter and Home Basic. In addition, Windows Server support does not include support for Windows Remote Desktop. Windows RT and tablets are not supported.

Recommended Software

Microsoft Internet Explorer 11.0 or later

Minimum Hardware

• Intel Pentium 4 or AMD Athlon XP 2000 with multi-core CPU
• 8 GB RAM
• Virtual memory is at least twice the physical memory
• 50 GB free disk space
• 1,024 x 768 display resolution with actual color (16-bit color)
• Broadband Internet connection for some service
• Ethernet card (for network communications and security hosted)
• Three-button Microsoft-compatible mouse

Recommended Hardware

• Intel Core 2 Duo 2.66 GHz or AMD Athlon 64 X2 5200+
• Note: Faster processors are preferred.
• 8 GB RAM
• 500 GB free disk space
• 1,280 x 1024 display resolution with true color (at least 32bit color)
• A dedicated graphics card
• Dual monitors
• Broadband Internet connection for some services
