DipTrace 4.3.0.5 for PC Windows

Description

Overview of DipTrace

This is EDA/CAD software for creating schematic diagrams and printed circuit boards. The developers provide a multi-lingual interface and tutorials.

It has four modules: Schematic Capture Editor, PCB Layout Editor with built-in shape-based autoroute and 3D Preview & Export, Component Editor, and Pattern Editor.

This powerful and intuitive software is aimed at professionals who want to create PCB layouts, design schematics, and edit components and patterns. With it, you can build anything from simple logic circuits to highly complex boards, which can view in both plane and 3D form.

Features of DipTrace

• Easy to learn User Interface
• Multi-sheet and hierarchical schematics
• Shape-based autorouter
• Smart manual routing tools
• Broad import/export capabilities
• High-speed signaling
• Advanced verifications and Real-time DRC
• Real-time 3D PCB preview & STEP export
• Manufacturing output
• Commitment to the future

Technical Details and System Requirements

• Supported OS: Windows 10, Windows 8.1, Windows 7
• RAM (Memory): 2 GB RAM (4 GB recommended)
• Free Hard Disk Space: 500 MB or more
