Dlubal COMPOSITE-BEAM v8.36.01.162532 x64 for PC Windows

Description

Dlubal COMPOSITE-BEAM is a program that enables the design of continuous composite beams according to the European standard ENV 1994‑1‑1:1992‑10. The module is built on the basis of a two-way connection between RSTAB 8 and the add-on modules. However, you do not need an RSTAB 8 license to use COMPOSITE‑BEAM (stand-alone work is possible). When importing the structural model, you can define single-span and continuous beams with or without cantilevers. In addition, it is possible to specify different span lengths with definable boundary conditions (supports, releases) as well as any construction supports and moment releases during the construction phase. For a complete cross-section, you can create typical composite beam sections based on steel beams (I-sections) with solid concrete flanges, precast slabs, trapezoidal sheets or conical solid roofs.

It is also possible to grade sections using the length of the beams, optionally with concrete cover. Illustrated shapes facilitate the insertion of additional transverse reinforcement for trapezoidal sheets, profile stiffeners and angular or circular openings in the web. Autoweighting is automatically applied when entering loads. In addition, it is possible to consider constant and variable loads by specifying the age of the concrete at the beginning of the loading for creep and to freely define single, uniform and trapezoidal loads. COMPOSITE-BEAM automatically creates a load combination based on the data of the individual load cases.

COMPOSITE-BEAM program features and functions

• Single-span and continuous beams with definable boundary conditions
• Automatic determination of effective cross sections
• Free arrangement of construction supports for the construction phase
• Concentrated, distributed and trapezoidal loads as fixed loads with specification of concrete age during loading
• Freely definable construction loads as well as dynamic construction loads
• Automatic load combination
• Calculation of cross-sectional properties according to method 1 or 2
• Calculation of elastic internal forces with RSTAB
• Redistribution of Moments
• Design of flexural and shear strength with interaction
• Determining the required shear connections and their distribution
• Longitudinal shear strength design
• Results of governing support reactions for construction and composite phases, including construction support loads
• Lateral-torsional buckling analysis
• Crack width limitation analysis
• Natural frequency design

System requirements

Operating systems:
– Windows 7 SP1 (x64)
– Windows 8.1 (x64)
– Windows 10 (x64)
Memory (RAM):  2 GB
Processor unit:  2 GHz
Graphics:  256 MB dedicated
