Dlubal SHAPE-MASSIVE v6.8 for PC Windows

Description

Dlubal SHAPE MASSIVE software is used to calculate the properties of thick-walled cross-sections independently of the main software. It determines the cross-sectional properties of each thick-walled cross-section and calculates the stresses. In addition, you can perform reinforced concrete design according to Eurocode 2 and other standards. For SHAPE-MASSIVE, there is a connection option to RFEM 5 and RSTAB 8: SHAPE-MASSIVE cross-sections are also available in the library of the finite element analysis software or the frame analysis software; and vice versa, RFEM and RSTAB internal forces can be imported and designed in SHAPE-MASSIVE.

It is possible to freely model a cross-section using surfaces bounded by polygonal lines, including openings and point areas (rebars). Alternatively, you can use the DXF interface to import the geometry. An extensive library of materials facilitates the modeling of complex cross-sections. The definition of limiting diameters and priorities allows for the reduction of reinforcement. In addition, you can take into account the concrete cover and the associated prestresses. SHAPE-MASSIVE is a specialized tool for the analysis and design of thick-walled cross-sections. It operates independently but can also be integrated with structural analysis software such as RFEM and RSTAB.

 Features and functions of the Dlubal SHAPE MASSIVE program

• Cross-section modeling using surfaces, openings, and point areas (reinforcements) bounded by polygons
• Automatic or separate arrangement of stress points
• Expandable library of concrete, steel and reinforcing steel materials
• Cross-sectional properties of reinforced concrete and composite sections
• Stress analysis assuming yield according to von Mises and Tresca
• Reinforced concrete design
• In addition to the National Annexes (NA) listed above, you can also define a specific NA and apply user-defined bound values ​​and parameters.
• Reinforced concrete design for stress-strain distribution, existing safety or direct design
• Results of reinforcement list and total reinforcement area
• Print report with short form print option

System requirements

Operating systems:
– Windows 7 SP1 (x86)
– Windows 8.1 (x86)
– Windows 10 (x86)

Memory (RAM) : 2 GB
Processor unit : 2 GHz
Graphics : 256 MB dedicated
