DS Simulia XFlow 2022 for PC Windows

Description

Overview of DS Simulia Xflow Benefits

XFlow offers particle-based Lattice-Boltzmann technology for high fidelity Computational Fluid Dynamics (CFD) applications expanding SIMULIA’s CFD portfolio. XFlow’s state-of-the-art technology enables users to address complex CFD workflows involving high-frequency transient aerodynamics with accurate moving geometries, complex multiphase flows, free surface flows, and fluid-structure interactions.

XFlow’s automatic lattice generation and adaptive refinement capabilities minimize user inputs, reducing time and effort in a typical CFD workflow’s meshing and pre-processing phase. This enables engineers to focus most of their efforts on design iteration and optimization rather than the time-consuming meshing process.

With XFlow’s discretization approach, surface complexity is also not a limiting factor. The underlying lattice can be controlled with a small set of parameters; the lattice is tolerant to the input geometry’s quality and adapts to moving parts’ presence.

In addition, advanced rendering capabilities provide realistic visualization to gain deeper insight into flow and thermal performance. XFlow’s unique capabilities enable companies to reduce physical testing and make better design decisions faster.

Overview of DS Simulia Xflow Features

• Co-simulations with Abaqus
• Co-simulation with Simpack via FMI standard
• Direct support of CATIA parts
• CST-XFlow one-way coupling
• Multiphase Volume of Fluid (VoF) solver
• Animated geometry behavior for simplified FSI analysis
• New thermal boundary conditions
• The Co-simulation Engine automatically performs a mutual exchange of information.

System Requirements and Technical Details

• Supported OS: Windows 7/8/10 (64bit)
• Processor: Quad Core or Dual Hexa Core i7 processors
• RAM: 12 GB RAM (24 GB recommended)
• Free Hard Disk Space: 5 GB or more
