IDEA StatiCa 21.1.4.1568 for PC Windows

Description

Overview of IDEA StatiCa 21 Benefits

IDEA StatiCa 9 has revolutionized the engineering world by being the first – and only – software to implement the new CBFEM method – based on finite element analysis – which allows the code-checking of steel connections of ANY geometry and loading. The software performs a non-linear plastic analysis for all the elements in the joint – plates, bolts, and welds. It supports pre-stressed bolts, anchoring, and particular contact elements between the plates.

IDEA StatiCa Connection designs and checks welded or bolted connections, 2D or 3D joints, anchoring, or footing of all topologies. We provide clear pass / fail checks according to EC / AISC / CISC standards in a complete report with drawings.

IDEA StatiCa Detail reinforces and checks all types of walls, beams, and details (in 2D) such as dapped ends, openings, hangings, brackets, diaphragms, frame joints, and many more.

Do your project from scratch or build on geometry and loading imported from Robot, Revit, MIDAS Civil + Gen, STAAD.Pro, SAP 2000, Scia Engineer, RFEM, RSTAB, AxisVM, ConSteel, etc. Take advantage of the link between IDEA StatiCa and Tekla Structures or Advance Steel to provide workshop drawings and support the manufacturing process.

Overview of IDEA StatiCa 21 Features

• Completely new, clean user interface
• New wizard for creating a connection
• Navigator replaced by Ribbon tabs
• Direct 3D scene commands
• Right mouse button commands
• Templates for manufacturing operations
• Plastic redistribution in welds as the only method
• Singularity warning
• Export of the report directly to Word and PDF
• AISC and CISC code requirement updates
• AISC formulas in results
• Stub manufacturing operation improvements

System Requirements and Technical Details

• Supported OS: Windows 11, Windows 10, Windows 8.1, Windows 7
• RAM (Memory): 2 GB RAM (4 GB recommended)
• Free Hard Disk Space: 800 MB or more
