Description
Keysight PathWave EM Design (EMPro) 2023 is a 3D electromagnetic (EM) modeling and simulation environment for analyzing high-speed and RF/microwave components, integrated with the PathWave Advanced Design System (ADS) workflow. The 2023 version includes usability improvements, features for simulating meta-materials, the ability to use S-parameters for frequency-dependent loads, and alignment with the ADS 2023 environment. It offers modern 3D modeling and high-capacity time- and frequency-domain simulation technologies, including Finite Element Method (FEM) and Finite Difference Time Domain (FDTD).
Core capabilities
- 3D EM modeling: Provides a modern, efficient environment for creating and importing 3D structures, defining material properties, and setting up simulations.
- Integration with ADS: Seamlessly integrates with the PathWave ADS design flow, allowing for co-simulation and analysis of 3D EM effects alongside circuit simulations.
- Advanced simulation: Utilizes both frequency-domain (FEM) and time-domain (FDTD) simulators to handle various design challenges, from high-frequency components to electrically large problems.
- Flexible modeling: Allows users to create arbitrary 3D shapes directly or import existing CAD files.
Key features in the 2023 release
- Meta-materials support: Adds the capability to simulate meta-materials.
- Frequency-dependent loads: Enhances design flexibility by allowing Circuit Components to be defined by S-parameter files for more general frequency dependency.
- Usability fixes: Includes various fixes to improve the user experience.
- ADS 2023 alignment: Synchronizes the FEM simulator with the PathWave ADS 2023 Update 1.0 release
