Mazak FG-CADCAM 2020 for PC Windows

Description

FG-CAD/CAM allows the user the flexibility to apply any cutout onto the part utilizing full axis movement for beveled processing or as a cutout applied perpendicular to the surface of the part for 2D processing of the cut. The nesting function allows you to combine various parts together on a common stick length for continuous processing in a single NC program.

FG-CAD/CAM allows the user the flexibility to apply any cutout onto the part utilizing full axis movement for beveled processing or as a cutout applied perpendicular to the surface of the part for 2D processing of the cut. The nesting function allows you to combine various parts together on a common stick length for continuous processing in a single NC program.

Shape materials automatically from imported data:
You can import IGES, DWG or DXF data and FG-CAD/CAM will create a 3D material shape from an arbitrary 2D shape.

Nine standard pipe and structural steel cross sections are included in the program menu to match the part you are processing quickly and easily. Thirty cutting conditions are available for each application designated under a material type and thickness. Additionally, cutting strategy files can be accessed to allow for specialized piercing or cutting techniques to be automatically applied.materials automatically from imported data.You can import IGES, DWG or DXF data and FG-CAD/CAM will create a 3D material shape from an arbitrary 2D shape. and many more…

Overview of MAZAK FG-CADCAM 2020 Features

• 2D CAD function
• 2D IGES input
• 2D DXF input
• 3D pipe design menus
• 3D IGES input
• Nesting Program simulation
• 3D laser processing of tube or structural shapes for the rotary axis
• Nozzle interference check
• 3D Parasolid input

Technical Details and System Requirements

• Supported OS: Windows 10 / Windows 8.1 /Windows 7 SP1 (x64)
• Processor: Dual Core, 2.8 GHz CPU or greater
• RAM: 8GB RAM or greater (depending on OS)
• Free Hard Disk Space: 40 GB available storage
• GPU: Dedicated graphics card capable of 1024 x 768 minimum resolution (32bit mode)
