OPTUM G3 2021 v2.1.6 x64 for PC Windows

Description

Optum G3 is a redesigned 3D finite element (3D FE) design tool for geotechnical engineers. Optum G3 is the ideal solution for the analysis and design of shallow foundations. Optum’s unique analysis type, called “Limit Analysis”, provides a way to determine bearing capacity efficiently and conveniently. Accurate upper and lower limits can be calculated to constrain the true solution from above and below, thus providing a built-in method for numerical verification. Elasto-plastic analysis is available to determine settlements.

Deep excavations are often risky operations that require careful planning and, as part of that, accurate and correct analysis. The reliability and efficiency of OPTUM G2 make it an ideal tool for simulating deep excavations. Accurate soil models and a wide range of tools and options are available for modeling retaining systems, from retaining walls to anchors and soil nails. The monopiles consist of a steel pile, typically 3 to 5 meters in diameter, driven into the ground by about 10 to 20 meters, depending on the ground conditions. OPTUM G3 provides all the tools necessary for the accurate analysis and design of monopiles, including limit analysis to assess ultimate capacity and elastoplastic analysis to determine displacements.

Program features and functions:

• Load-Displacement Analysis – FEM: Accurate and realistic assessment of displacements is an essential part of many design tasks. With a variety of elastoplastic and consolidation analyses, a wide range of problems can be designed effectively. Step-by-step analysis by activating and deactivating regions in the solid model – not in the meshed model – has never been easier.
• Calculate ultimate loads – in one step! Access the most advanced FE capabilities on the market – designed and made available for operational engineers. With unique built-in limit analysis options, you can now calculate bearing capacity in one step. Use this unique and ultra-fast analysis type in conjunction with traditional elastoplastic analysis and move faster and safer than ever before.
• 3D Redesigned – Faster than Ever: For many geotechnical engineers, 3D FE analysis is considered the last resort to complete a design – mainly due to the complexities of model setup combined with extremely long processor times. A new chapter begins with OptumG3. Using the unique MIXED element, users can calculate bearing capacity with unprecedented accuracy in seconds. Validate with upper and lower limit calculations and calculate load-displacement curves using the elastoplastic analysis feature.
• Model Creation – Intuitive and Fast: Setting up models and defining geometry in 3D has never been easier. OptumG3 comes with advanced built-in 3D modeling tools that allow the user to create 3D models with almost the same ease as in 2D. For more complex geometries, you can import IGES and STEP files and continue working on the imported geometry. Add interfaces and skins with the same ease as in G2.

System requirements

Operating System :

• Microsoft® Windows® 7 SP1 with Update KB4019990 (64-bit)
• Microsoft Windows 8.1 (64-bit)
• Microsoft Windows 10 (64-bit)

CPU Type : 64-bit Intel Multicore processor or AMD Athlon 64 processor
Memory Required : 4GB
Recommended : 8 GB
Display Resolution Basic : 1024 x 768 pixels, 32-bit color palette
Recommended : 1920 x 1080 pixels, 32-bit color palette
Disk Space : 6 GB
.NET Framework : .NET Framework Version 4.5.2
