PC SCHEMATIC Automation 40 v20.0.3.54 for PC Windows

Description

It is the intelligent electrical design software for electrical engineering. This software is the professional choice for drawing schematics for electrical wiring diagrams, control circuit diagrams, pneumatics and hydraulics.

Automation has an intuitive workflow, which allows you to get started right away – well supported by the free tutorials on the PCSCHEMATIC YouTube channel.The software handles reference designations intelligently according to IEC/ISO 81346, and includes symbols for automation, PLCs, topology / bus connections, single line diagrams, pneumatics/hydraulics, house installation and more..

This PCSCHEMATIC Component Database contains 45.485 components from 51 manufacturers. Each record contains electrical and mechanical symbols – as well as article data for the component.

Overview of PC SCHEMATIC Automation 20 Features

• For each line data field, it is now possible to set their visibility in the drawing, adding the line data field to the value in the List Element and BOM list of material.
• Listing links in the form of a project page, there was only a List of links to a file (xls, xml, txt).
• Additionally, the schematic can be used to individually change the connection type of two connections from a dot to a branch (fork, etc.) and vice versa, and the change can be made to the selected line, the selected area, or the entire page.
• For all texts it is possible to add a reference line with an arrow in the drawing .
• From this version, the program remembers the header status of each project page , so if a page header is swapped after another, the new header will be set to the same state (if it also has one).
• If you want to replace the PCSCHEMATIC font other than in the font list, you can use the OSI font , which is free to download.
• Now it is possible to set the number of keystrokes after which the program wraps text written in the text editor to the next line. Settings can be made for all project pages or just for statements.
• The Assembly Assistant now has the ability to add joint notes, set display filters, and open an external file (assembly instruction) from the module environment.
• Enhanced Database Recorder Assistant allows you to create a “3D part model” with the new AutoMech Database Field and enter part dimensions, pin locations, pin type (termination) and mounting direction.

Technical Details and System Requirements

• Supported OS: Windows 7/8/10
• Processor: Pentium IV or above
• RAM: 1 GB RAM
• Free Hard Disk Space: 500 MB or more
