PentaLogix ViewMate Pro 2025 for PC Windows

Description

When using ViewMate Pro, with Smart DFM, you can check data for a host of violations. And not just one layer at a time! Multiple violations, multiple layers with fast, accurate results. The system provides an ASCII error report and, in addition, creates a Gerber file that makes correcting plot files a snap.

It also contains built-in filleting, silkscreen clipping, draw-to-flash, venting, and thieving. You set the parameters once; the system does the rest. Fast and accurate, every time. Moreover, you need not rely on guessing what your circuit board will look like. No more waiting for photo-plots or worse, your prototype circuit board, to see your true design. With ViewMate Pro and Smart DFM, you can rest assured that the capabilities you need for today’s and tomorrow’s challenges are there when you need them.

Overview of PentaLogix ViewMate Pro Features

• Smart DFM automated design for manufacturing checks and corrects
• DXF File Converter
• Import multiple net-list formats
• Venting & Thieving
• Filleting
• Fill Polygons
• Solder-mask Generation
• Overlap Correction
• Draw to Flash Pad Conversion
• Snap to Padmaster
• Easily Quote and Order circuit boards within your design
• Copper area calculation
• Solder-mask generation
• Copper pouring
• Silkscreen clipping
• Automated Venting & thieving
• Board Cleanup Functions
• One year of free technical support

Technical Details and System Requirements

• Supported OS: Windows 7/8/10/11
• Processor: Pentium IV or above
• RAM: 1 GB RAM
• Free Hard Disk Space: 500 MB or more
