ProfiCAD 12.4.6 for PC Windows

Description

Overview of ProfiCAD

ProfiCAD 10 is an easy and budget-friendly program for electrical engineering drawings or wiring diagrams of electrical engineering. Even untrained users can produce high-quality drawings with ProfiCAD.

The program generates a netlist, material bill, and wires list. Electrical symbols are numbered automatically. Can export diagrams to DXF format. Can easily paste the drawings created by the program into Microsoft Office and other programs. Thanks to Unicode technology, texts in any language are to be inserted.

Features of ProfiCAD

• The most accessible CAD for electrical circuits. Maximum care was paid to ergonomics and ease of use. Just place electrical symbols into the drawing and attach the wires.
• Ships with more than one thousand symbols. You can easily create symbols in the symbols editor or draw them for a fee.
• Supports automatic numbering of symbols, generation of netlists, lists of wires, bills of material, drawing of striped wires, and other advanced features.
• The program supports cross-references between wires and symbols belonging to one component (e.g., relay coil + contacts). A linked symbol on a different page can be accessed by clicking the cross-reference.

Technical Details and System Requirements

• Supported OS: Windows 11, Windows 10, Windows 8.1, Windows 7
• RAM (Memory): 2 GB RAM (4 GB recommended)
• Free Hard Disk Space: 200 MB or more
