Rocscience RocTunnel3 v1.0 x64 for PC Windows

Description

Rocscience’s RocTunnel3 is a cutting-edge 3D rock stability analysis software designed for underground excavations. It uses the boundary element method to perform 3D stress analysis, making it ideal for large-scale structures like mines, tunnels, and caverns. Find valid block formations by intersecting joints and calculate the factor of safety in deterministic analysis. You can sample rock unit weights, joint shear strength, and water pressure across simulations to calculate block failure probability. Analyze block stability and the required support pressure and support depth in every construction stage for meeting a user specified design target. Design shotcrete, support pressures, and bolts in stages to address the challenges of structurally controlled failures underground. Model realistic 3D underground excavations in complex geological domain and structurally controlled failures in rock. Easily import and update geometry and joint field data, and you can export geometries of the excavation, blocks, and block failure information.

Features of Rocscience RocTunnel3 :

• Geometry Modeling: Import various 3D geometries and design excavations.
• Surface Meshing: Simplifies and efficiently discretizes the model.
• Elastic Stress Analysis: Analyze stress distribution and displacement.
• Data Visualization: Visualize results on the mine’s surface and at pre-defined field points.
• Integration with RS3: Seamlessly import models from RS3 for comprehensive analysis.
• User-Friendly Interface: Robust and efficient for analyzing complex underground mining excavations

System Requirements

Operating System

Windows 10 (64-bit), Windows 11 (64-bit)

RAM

Minimum requirement : 32 GB
Recommended for terrain meshes > 100,000 triangles: 64 GB

Storage
